3D Printing the Future of Rail at Deutsche Bahn

Deutsche Bahn is investing heavily in additive manufacturing. How can they best incorporate this technology into their future supply chain?

Deutsche Bahn (DB) is a German state-owned global mobility and logistics provider. Their passenger transport division moves 7 million rail passengers daily, with over 80% of those trips occurring in Germany.[1] At the leading edge of adopting additive manufacturing (AM) in rail, DB has made a public commitment to incorporate this technology into its supply chain. While DB does not own its own 3D printers, it collaborates with industry to employ this technique.[2] To date, AM has allowed DB to better manage parts availability to reduce rolling stock downtime and inventory costs.

DB’s annual report summarizes their AM strategy: “To maintain vehicles we need spare parts to be available immediately. Printing is faster and more flexible than conventional manufacturing processes and the vehicles are back in operation in no time at all.”[3] Maintenance demand for many rail components is irregular, often in small quantities, and missing parts are a problem. With traditional manufacturing and procurement processes, there is a clear tradeoff between the costs of holding excess inventory of spare parts and the potential for rolling stock downtime and missed trips. For many components, AM eliminates this tradeoff.

The clearest opportunity for DB to employ AM in its supply chain is for older, out-of-production (obsolescent) parts for which replacement is unscheduled and missing parts are common.[4] For Siemens-built ICE-1 trains manufactured from 1989 to 1993, AM has reduced ICE-1 train downtime when failures require replacement of some obsolete parts.[5] Both Siemens and DB benefit from this technique. Siemens reported that 3D printing is cheaper, custom parts production is reduced from six weeks to thirteen hours, and Siemens no longer casts excess parts for its own inventory.[6]

DB has also found that the total costs of 3D printing can be below traditional manufacturing and procurement costs. For one component (a heat exchanger for electric trains), a DB study found that although the unit cost to procure these parts from traditional manufacturers was below the cost to print them with AM partner 3YourMind, reduced inventory carrying costs from just-in-time production offsets this initially lower procurement cost and justifies 3D printing.[7]

Deutsche Bahn and BigRep discuss their partnership:

DB has developed a clear strategy to promote adoption of AM. Internally, DB has committed significant resources to AM with a team of seven full-time and forty part-time employees from across the organization working on the program.[8] As a result, AM is deployed across DB, not just in rail maintenance: for example, printed parts include handrails coated in braille to improve mobility for the blind in stations.[9]

Because DB is relying on third parties to produce 3D-printed parts, a key component of their strategy has been to develop and formalize the AM industry. Externally, DB has proactively formed partnerships in the industry. The “Mobility Goes Additive” initiative, led by DB’s Head of Additive Manufacturing, has grown from 9 to over 80 participants (e.g. Swiss Federal Railways, Austrian Federal Railways, Siemens, 3YourMind, Big Rep) in the last two years, and focuses on knowledge transfer and the development of profitable partnerships.[10][11][12] As of June 2018, DB’s logistics arm became the world’s first logistics service to offer AM services, coordinating 3D printing from its third party printing partners with delivery through an online portal.[13]

Additionally, DB has communicated AM volume goals to the market, further encouraging suppliers. In 2016, they produced 1,000 parts, for 2017 they set a goal to produce 2,000 parts, and for 2018, 15,000 parts.[14] Volume commitments, and other communications about the importance of AM for DB will encourage long-term investments by its private sector partners and other rail operators.

To promote AM adoption, DB should consider incorporating AM into future rolling stock procurements. For all new trains, manufacturers could be responsible for providing 3D printing blueprints as a part of maintenance materials. New trains could rely on a mixture of AM and traditional procurement for ongoing maintenance, allowing DB flexibility to optimize maintenance strategy from train introduction. Furthermore, the costs of obsolescent part management will be significantly reduced if 3D designs have already been obtained.

Second, DB Engineering & Consulting (E&C) could pursue consulting business to convert other rail operators to AM. Not only could this produce revenues from numerous customers, this work would align with DB strategy to promote adoption across the rail industry.

Looking forward, DB has stated that they may want AM in-house. DB’s focus has been identifying parts to print and finding external partners to print for them. Should DB pursue in-house printing? If so, what capabilities would DB need to develop?

Furthermore, if DB decides to pursue in-house printing, should DB limit themselves to only certain types of products? Should they focus on producing non-critical parts (e.g. braille handrails) that are not safety-sensitive and require less precision, or should they pursue production of safety-sensitive, flame retardant train components?
